BE 3,500 PSI - 5.6 GPM Spitfire Truck/Trailer Mount Hot Water Pressure Washer with Honda GX690 Engine and General Triplex Pump - Industrial Series

Powerful Honda GX690 engine with electric start drives the pump. A 55AH Marine battery is included.

Belt drive system provides longest pump life possible by lowering its heat, vibration and RPM.

Industrial grade General triplex pump featuring reinforced body, forged brass manifold, solid ceramic plungers, stainless steel check valves and thermal release valve.

External unloader provides superior cooling and versatility to further enhance pump life.

Heating coil is ignited by a 12v Beckett burner that is fueled by diesel.

The burner can be turned off and controlled with the adjustable thermostat that can be set up to 93°/200°F.

Industrial grade accessories included are a 50 foot high-pressure hose, spray gun wand assembly, and five spray nozzles.

Powder coated steel frame with 1.5" OD roll cage that is designed to mount onto a truck or a trailer.

Oil drain hoses on the engine and pump allow for easier maintenance with less mess.

The actual product may vary from the images shown on the website.

SHIPPING INFORMATION
WEIGHT: 975LBS
DIMENSIONS (LxWxH): 48"x46"x51"

ENGINE

• MODEL: HONDA GX690
• TYPE: AIR COOLED, 4-STROKE OHV
• DISPLACEMENT: 688CC
• FUEL TYPE: 86 OCTANE, UP TO 10% ETHANOL
• FUEL TANK: 14.4 GALLON
• OIL TYPE: SAE 10W30

PUMP SPECS

• MODEL: GENERAL TSF2021
• TYPE: TRIPLEX
• PART NUMBER: 85.130.026B
• OIL TYPE: 30W NON-DETERGENT
• SOAP SYSTEM: ADJUSTABLE INJECTOR

UNLOADER

• TYPE: EXTERNAL W/36" HOSE
• PART NUMBER: AL60

BURNER

• THERMOSTAT: ON/OFF AND ADJUSTABLE
• MAX HEAT: 93°C / 200°F
• IGNITER: 12V BECKETT BURNER
• HEATING COIL: 1/2" COLD ROLLED STEEL
• COIL TUBE LENGTH: 96' LENGTH OF TUBING
• FUEL CAPACITY: 14.4 GALLON
• FUEL TYPE: #1, #2 DIESEL OR KEROSENE

FRAME

• MATERIAL: POWDER COATED

WARRANTY

• ENGINE: 3 YEARS
• PUMP: 5 YEARS
• HEATING COIL: 3 YEARS
• UPC: 777897309010

ACCESSORIES

• HOSE TYPE: 50' X 3/8" WIRE BRAIDED
• PART NUMBER: 85.238.251
• NOZZLES: 0°, 15°, 25°, 40° AND SOAPER
• PART NUMBER: 85.210.060H
• GUN WAND: 47" INSULATED
• PART NUMBER: 85.205.066H
• FITTINGS: QUICK CONNECT
